TECHNICAL DRAWINGS

  • Drawings are set to inch-scale
  • Click drawing above to open full size schematic
  • Right-click and select "save Picture/Image as..."











6.5" LED SPOT/FLOOD LIGHT

Wide-beam light provides illumination for back-up, trailer hitch, load/unload or site lighting, as needed. Versatile and useful light on almost any type of equipment or vehicle.



  • 34 LEDs
  • 2900 RAW / 1700 EFFECTIVE LUMENS
  • OFF-ROAD TOUGH
  • WEATHERPROOF / DUSTPROOF / RUSTPROOF /  SHAKEPROOF
  • 30,000 HOURS – LONG LASTING



HiLUMEN SERIES™
44% wider beam spread than our standard lightbar, perfect for illumination of uneven terrain



SPECIFICATIONS

Voltage: 12-24V

Amp: 1.43A

Waterproof: Yes

Weight: 10 oz

Housing Material: Die-Cast Aluminum

Lens Material: High-Impact Polycarbonate

Light Temperature: 6500K



INCLUDES

  • Adjustable Mounting Bracket
  • All Hardware and Instructions to Mount the System



INSTRUCTIONS

Instruction Sheet



WARNING

Please check local and state laws before installing this product onto your vehicle
